FROG 500
DESCRIPTION
A lift unique in its kind, FROG 500 was designed for maintenance of tractor mowers as well as 4 wheeled vehicles, such as Quads and ATVs. lt is equipped with two elevating and tilting platforms that can raise up to 100 cm in the front end and to 155 cm in the rear end. This exclusive design solution allows a much easier access to the lower part of the vehicle and to operate in full safety and comfort and with a shorter working times.
DATA SHEET
F500-002 Air pump
F500-003 Electro-hydraulic pump
F500-004/R Electro-hydraulic pump with remote control
Load capacity: 500 Kg
Max. height (horizontal position): 80 cm
Min. height: 20 cm
Max. height (front part): 100 cm
Max. height (rear part): 155 cm
Wheel stopper: 2
Safety lock positions: 3
Max. rail distance (external): 130 cm
Min. rail distance (external): 101 cm
Rail size: 200×26 cm
Max. rail distance (internal): 74 cm
Min. rail distance (internal): 48 cm
Run-up ramp dimensions: 82×24 cm
Overall lift dimensions: 200×130 cm
Weight: 285 Kg
ELECTRO-HYDRAULIC CONTROL UNIT
Power: 1.1 Kw
Europe: 230 Volts
Japan: 200 Volts
America: 110 Volts
AIR PUMP
Air pressure: 7-10 Bar
Air consumption: 300L/Min
STANDARD EQUIPMENT
Ramps: 2
Standard packaging: wood crate 300 Kg
Wheel stopper: 4
